Reach All-In-One: capture, encode, mix, record and distribute in a single solution

Reach proposes a new generation equipment for recording and streaming audiovisual content, the Reach All-In-One server (SD series DSS-R-CL210), capable of capturing, encoding, mixing, recording and distributing content, all in a single device, designed especially for business meeting environments, as well as online training or distance education.

Reach proposes a new generation of equipment for recording and streaming audiovisual content, the REACH All-In-One server (SD series DSS-R-CL210), capable of capturing, encoding, mixing, recording and distributing content, all in a single device, designed especially for the education and business sectors.

Characterized by its compact size and portability, it integrates video, audio and VGA signal input interfaces, as well as high definition HDMI, VGA and audio output interfaces.

Supports any combination for recording, live broadcast broadcast and/or video on demand, of the different input sources; SD video, VGA and audio, thus obtaining a recorded file that includes both a VGA stream and a switchable video stream.

The high-definition HDMI and VGA outputs facilitate synchronized recording between video, audio and PC signal while obtaining a local preview and playback. Therefore, the needs for recording and reproducing audiovisual information that the end user may have in business meetings, as well as online training or distance education, are satisfied.

Technical characteristics

Administration and management
• Web interface.
• Centralized control system (AMX, Creston, etc.).
• Panel Frontal (One Button Recording).
• Reach General Management Platform (DSS-R-TMS).

Coding
• Vídeo: WMV-HD/H.264.
• Audio: WMA/AAC.

Multi-recording mode
• 1xSD Video (CIF, 4CIF) + 1xStereo Audio.
• 1xHD Video (720p, 1080i, 1080p) + 1xAudio estéreo.
• 1xVGA (1400×1050) + 1xStereo Audio.
• 1xSD Video + 1xVGA + 1xStereo Audio.
• 1xSD Video + 1xHD Video + 1xStereo Audio.

File storage and management
• Internal hard drive with 500G capacity.
• Network storage (FTP).
• Modification of file properties through web interface.

PlayBack
• RecPlayer.
• Microsoft Media Player.
• Reach Set-Top box.
