Sonifex launches the new CM-CU1 commentator position at Broadcast Asia

This equipment stands out for offering the same quality and robustness as its “big brother” CM-CU21, with a set of applications adapted to a simple commentary position.

The new CM-CU1 station is the latest addition to the family of commentator systems from the British Sonifex. This equipment stands out for offering the same quality and robustness as its “big brother” CM-CU21, with a set of applications adapted to a simple commentary position.

The equipment has all the functions of a position of this type with line-level entry. It has a single commentator output, with an additional output providing a mix of the commentator and line input.

The line input can be configured to remain present even if the commentator is not on air, which is very useful for effects or pre-recorded material. The presence of the commentator in the headphones can also be configured.

Four intercom output channels, with a built-in limiter, are available to the commentator and can be linked to provide simultaneous operation. Activating one or more intercom channels removes commentator audio from the main output until the intercom channels are disabled.
Input gain and switchable phantom power allow support for a variety of microphones including microphones. The unit features five flyback transformer balanced audio inputs which, along with the commentary input, are routed to the headphone monitor controls. With these headphone controls, any monitor input can be adjusted and sent to either the left, right, or both ears.

The unit also incorporates a line-up tone generator for channel identification and easy wiring control. When activated the test tone is directed to the desired output simply by pressing the corresponding button on the air or intercom. An automatic tone mode repeatedly sends different amounts of tone bursts to each output making it easy for the technician to configure.

Note that a locking system prevents accidentally activating the On-Air button.

The CM-CU1 unit is powered from a universal mains input of between 85 to 264 V AC at 47-63Hz, or from a 12-24V DC input.
