New frames and 3G-SDI expansion cards for PESA Cheetah

The Cheetah series of 3G-SDI frames is based on the latest copper-based transmission technology and can currently support distances of up to 140 meters.

PESA announced at NAB that its new coaxial extended range routing matrix frames are now available. The Cheetah series of 3G-SDI frames is based on the latest copper-based transmission technology and can currently support distances of up to 140 meters. The new frames and expansion cards can be seen at NAB 2013.

Each input card provides sixteen channel connectivity and includes the latest technology for perfect frame equalization up to 1080p/60. Each output card provides sixteen channel connectivity and extends SD-SDI signals up to 400m, HD-SDI up to 200m and 3G-SDI up to 140m.
Dan Holland, vice president of product marketing at PESA, commented: "Our new routing frames can extend 3G-SDI signals over the length of a football field. As an added feature, the input and output cards can be used to upgrade existing field units to deliver the pristine image quality expected from PESA."

The new extended scope routing frames are available in sizes ranging from 64x64 to 576x576. Larger systems can be configured to support up to 1152x1152. New Cheetah input and output cards and new frame shipments Cheetah routing matrices will include the new input and output cards when BNC versions are needed.
