CCTV installs Lawo V__matrix in the first all-IP mobile studio in China

The project's multi-display design is based on three Lawo V__matrix systems using 19 C-100 core processing modules and 19 Lawo vm-dmv Virtual Module installations.

China Central Television (CCTV) has launched the first complete mobile IP video system for video production. This first mobile studio project in China uses software-defined IP multi-display, processing and routing platform Theirs V__matrix as its core technological infrastructure.

CCTV, together with Lawo China and its partner Acro-bright, worked in cooperation with China's regional system integrator, Beijing Yutian, to achieve this success, the latest in a series of joint Lawo/CCTV installations including HD/UHD mobile units, audio SCRs, and studios at CCTV's Beijing headquarters.

The UHD 4K designed mobile studio facility, originally planned to play a central role during the 2020 Summer Games broadcasts from Tokyo, began construction in January 2019 under the supervision of CCTV's Production Department. The design of the project's multiscreen is based on three Lawo V__matrix systems that they use 19 C-100 core processing modules y 19 Virtual Modules of the Lawo vm-dmv, the world's first infinitely expandable true IP multi-display.

The facility also has twelve chains of cameras Sony UHD there is EVS. The IP network configures a backbone that uses switches Huawei for the backbone infrastructure, with two CE8850 switches for the redundant design core and four CE6865 switches as leaves. Both the mixers and the cameras have been supplied by Sony.

IP video processing

“Lawo became not only a strong reference in audio consoles, but also in IP video processing,” says a CCTV video engineer. “The success of this project was only possible with Lawo, as the vm-dmv multi-display solution, with its single 12G link for both IP and baseband signals, offers true 4K performance with extremely low latency.”

For CCTV, the main benefits of the Lawo vm-dmv lie in its design as a true IP-based 4k UHD multi-display, with the most advanced concept available on the market for a 40G network environment.

CCTV has been using Lawo mixing consoles since 2007, and is highly satisfied with their performance, flexibility, reliability and security, especially in critical broadcast and sports production environments. Given this relationship over many years, CCTV has also relied on Lawo video technology, noting that “Lawo has always looked forward in technology, and enjoys a good reputation for quality and performance.”
